- Hex finished nuts are considered the most commonly used hex nuts.
- DIN 934 hex nuts are the most commonly used metric hex nuts.
- Also known as regular hex nuts.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Type 316ti stainless steel is a titanium-stabilized version of type 316 stainless steel.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M10
- Thread Pitch: 1.5
- Diameter (Dimension): 10mm
- Thread Length (Nominal): 8mm
- Across Flats (Basic): 17mm
- Across Flats (Minimum): 16.73mm
- Across Flats (Maximum): 17mm
- Height (Basic): 8mm
- Height (Minimum): 7.64mm
- Height (Maximum): 8mm
- Washer Face Diameter (Minimum): 15.3mm
PRODUCT ATTRIBUTES- Category: Hex Finished Nuts
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Drive Style: External Hex Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: AISI 316Ti Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 934 / ISO 4032
Product UPC Code:
692559700199
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME594-1015X8X17
- Coating:
- Uncoated
- System of Measurement:
- Metric
- Thread Pitch:
- 1.5
- Category:
- Hex Finished Nuts
- Height (Maximum):
- 8mm
- Across Flats (Maximum):
- 17mm
- Drive Style:
- External Hex Drive
- Shop by Material:
- Stainless Steel
- Material:
- Stainless Steel
- Height (Basic):
- 8mm
- Height (Minimum):
- 7.64mm
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME594-1015X8X17.zip
- Standards and Specifications:
- DIN 934 / ISO 4032
- Product Class:
- Internally Threaded Fasteners
- Across Flats (Minimum):
- 16.73mm
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product38/ME594-1015X8X17.PDF
- Material Grade:
- AISI 316Ti Stainless Steel
- Shop by System of Measurement:
- Metric
- Diameter (Dimension):
- 10mm
- Brand:
- Aspen Fasteners
- POS:
- ME594-1015X8X17-000200
- Thread Length:
- Full Thread
- Thread Length (Nominal):
- 8mm
- Diameter (Nominal):
- M10
- Across Flats (Basic):
- 17mm
- Thread Direction:
- Right-Hand Thread
- Order:
- Nuts
