- Also known as tall nuts, hex high nuts offer a greater surface area for wrenching.
- Hex high nuts are much thicker than regular hex nuts allowing for increased thread engagement.
- Similar to a flange nut, the integrated collar offers a larger bearing surface.
- A4 stainless steel is functionally equivalent to 316 grade and is also known as "marine grade".
- Stainless steel significantly improves resistance to tarnishing or corrosion.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M24
- Thread Pitch: 3.0
- Diameter (Dimension): 24mm
- Thread Length (Nominal): 36mm
- Across Flats (Basic): 36mm
- Height (Basic): 36mm
- Flange Diameter: 45mm
- Flange Thickness: 6mm
PRODUCT ATTRIBUTES- Category: Hex High Nuts with Collar
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Length 1.5 X Diameter
- Drive Style: External Hex Drive
- Thread Length: Full Thread
- Thread Direction: Right-Hand Thread
- Material: Stainless Steel
- Material Grade: A4 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: DIN 6331
Product UPC Code:
692559700670
- Thread Direction:
- Right-Hand Thread
- Diameter (Dimension):
- 24mm
- Product Class:
- Internally Threaded Fasteners
- Diameter (Nominal):
- M24
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME600-2430X36X45X36.zip
- System of Measurement:
- Metric
- Form and Design:
- Length 1.5 X Diameter
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product38/ME600-2430X36X45X36.PDF
- Shop by Material:
- Stainless Steel
- Thread Length:
- Full Thread
- Category:
- Hex High Nuts with Collar
- Material:
- Stainless Steel
- Height (Basic):
- 36mm
- Flange Thickness:
- 6mm
- Material Grade:
- A4 Stainless Steel
- Thread Length (Nominal):
- 36mm
- POS:
- ME600-2430X36X45X36-000010
- Shop by System of Measurement:
- Metric
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME600-2430X36X45X36
- Flange Diameter:
- 45mm
- Drive Style:
- External Hex Drive
- Order:
- Nuts
- Thread Pitch:
- 3.0
- Coating:
- Uncoated
- Across Flats (Basic):
- 36mm
- Brand:
- Aspen Fasteners
- Standards and Specifications:
- DIN 6331
