- Superior quality parts by Holo-Krome, made in the U.S.A.
- Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
- Flat countersunk head screws sit flush with the surface of the material they are inserted into.
- An internal hex socket drive is also known as an Allen drive.
- Class 12.9 steel is an alloy steel, quenched and tempered, with a minimum tensile strength of 1,220/mm-2 (Mpa).
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M4
- Thread Pitch: 0.7
- Diameter (Dimension): 4mm
- Diameter (Minimum): 3.82mm
- Diameter (Maximum): 4mm
- Length (Nominal): 15mm
- Thread Length (Nominal): 12.7mm
- Drive Recess Size: 2.5mm
- Drive Recess Width: 2.5mm
- Drive Recess Depth: 1.8mm
- Drive Recess Depth (Minimum): 1.55mm
- Drive Recess Depth (Maximum): 1.8mm
- Head Diameter: 8mm
- Head Diameter (Minimum): 7.64mm
- Head Diameter (Maximum): 8mm
- Head Height, Overall: 2.3mm
PRODUCT ATTRIBUTES- Category: Socket Head Cap Screws
- System of Measurement: Metric
- Brand: Holo-Krome®
- Head Style: Flat Countersunk Head
- Head Style Detail: 90 Degree Countersink
- Drive Style: Hex Socket Drive
- Threading: Thread Class ANSI B1.13M
- Thread Length: Part Thread
- Thread Direction: Right-Hand Thread
- Material: Steel
- Material Grade: Class 12.9 Steel
- Material Processes: Heat Treated
- Coating: Oxidized
- Coating Color: Black
- Origin: Made in U.S.A.
- Standards and Specifications: DIN 7991 / ISO 10642
