M4-0.7 X 8mm ISO 7380-1, Metric, Button Head Hex Socket Cap Screws, Holo-Krome, Class 12.9 Steel, Black Oxide

PART NUMBER:
HK001-407X8X25-000500
Free Shipping Free ground shipping to the 48 contiguous US states.
Normal delivery time 2-3 days.
For more information, visit our Shipping and Deliveries page.
(No reviews yet) Write a Review
PACK QUANTITY PRICE PER PACK Availability SELECT NUMBER OF PACKS Add to cart
question By saving items to your Saved Items lists, you can quickly and easily organize and retrieve the parts that are important to you. Your can create and name as many lists as you require and add as many parts as you need to each of your lists.
  • Superior quality parts by Holo-Krome, made in the U.S.A.
  • Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
  • Button head screws have a wider bearing surface and maintain a low head profile.
  • An internal hex socket drive is also known as an Allen drive.
  • Class 12.9 steel is an alloy steel, quenched and tempered, with a minimum tensile strength of 1,220/mm-2 (Mpa).
DIMENSIONAL ATTRIBUTES
  • Diameter (Nominal): M4
  • Thread Pitch: 0.7
  • Diameter (Dimension): 4mm
  • Diameter (Minimum): 3.82mm
  • Diameter (Maximum): 4mm
  • Length (Nominal): 8mm
  • Thread Length (Nominal): 8mm
  • Drive Size: 2.5mm
  • Head Diameter: 7.6mm
  • Head Diameter (Minimum): 7.24mm
  • Head Diameter (Maximum): 7.6mm
  • Head Height, Overall: 2.2mm
  • Head Height, Overall (Minimum): 1.95mm
  • Head Height, Overall (Maximum): 2.2mm
PRODUCT ATTRIBUTES
  • Category: Socket Head Cap Screws
  • System of Measurement: Metric
  • Brand: Holo-Krome®
  • Head Style: Button Head
  • Drive Style: Hex Socket Drive
  • Threading: Thread Class ANSI B1.13M
  • Thread Length: Part Thread
  • Thread Direction: Right-Hand Thread
  • Material: Steel
  • Material Grade: Class 12.9 Steel
  • Material Processes: Heat Treated
  • Coating: Oxidized
  • Coating Color: Black
  • Origin: Made in U.S.A.
  • Standards and Specifications: ISO 7380-1
Product UPC Code:
692559870656
Head Height, Overall (Minimum):
1.95mm
Shop by Material:
Steel
System of Measurement:
Metric
Recess Size:
2.5mm
Head Diameter:
7.6mm
Length (Nominal):
8mm
Standards and Specifications:
ISO 7380-1
Diameter (Nominal):
M4
Origin:
Made in U.S.A.
Drive Style:
Hex Socket Drive
Thread Direction:
Right-Hand Thread
Material Grade:
Class 12.9 Steel
Shop by Application:
Socket Products
Thread Length (Nominal):
8mm
Head Height, Overall (Maximum):
2.2mm
Threading:
Thread Class ANSI B1.13M
Coating Color:
Black
Material:
Steel
Category:
Socket Head Cap Screws
Head Diameter (Maximum):
7.6mm
Diameter (Maximum):
4mm
Diameter (Dimension):
4mm
Order:
Machine Thread Fasteners
Shop by System of Measurement:
Metric
Material Processes:
Heat Treated
Head Diameter (Minimum):
7.24mm
Product Class:
Externally Threaded Fasteners
Thread Length:
Part Thread
Coating:
Oxidized
Head Style:
Button Head
Diameter (Minimum):
3.82mm
Head Height, Overall:
2.2mm
Thread Pitch:
0.7
Brand:
Holo-Krome(r)
  • Description
    • Superior quality parts by Holo-Krome, made in the U.S.A.
    • Socket cap screws are precision fasteners often used in machine parts, die fixturing and clamping.
    • Button head screws have a wider bearing surface and maintain a low head profile.
    • An internal hex socket drive is also known as an Allen drive.
    • Class 12.9 steel is an alloy steel, quenched and tempered, with a minimum tensile strength of 1,220/mm-2 (Mpa).
    DIMENSIONAL ATTRIBUTES
    • Diameter (Nominal): M4
    • Thread Pitch: 0.7
    • Diameter (Dimension): 4mm
    • Diameter (Minimum): 3.82mm
    • Diameter (Maximum): 4mm
    • Length (Nominal): 8mm
    • Thread Length (Nominal): 8mm
    • Drive Size: 2.5mm
    • Head Diameter: 7.6mm
    • Head Diameter (Minimum): 7.24mm
    • Head Diameter (Maximum): 7.6mm
    • Head Height, Overall: 2.2mm
    • Head Height, Overall (Minimum): 1.95mm
    • Head Height, Overall (Maximum): 2.2mm
    PRODUCT ATTRIBUTES
    • Category: Socket Head Cap Screws
    • System of Measurement: Metric
    • Brand: Holo-Krome®
    • Head Style: Button Head
    • Drive Style: Hex Socket Drive
    • Threading: Thread Class ANSI B1.13M
    • Thread Length: Part Thread
    • Thread Direction: Right-Hand Thread
    • Material: Steel
    • Material Grade: Class 12.9 Steel
    • Material Processes: Heat Treated
    • Coating: Oxidized
    • Coating Color: Black
    • Origin: Made in U.S.A.
    • Standards and Specifications: ISO 7380-1
    Product UPC Code:
    692559870656

Contact us for availability information on part number HK001-407X8X25-000500. Please chat with us, call us, e-mail us, or use the form below. Our customer support team will find the best delivery options for you.
