- Particle board screws are designed for use in dense woods such as particle boards or chipboards.
- A 6-lobe recess is also known as a hexalobular internal drive.
- Pan head screws are also known as raised cheese head screws.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M4
- Diameter (Dimension): 4mm
- Length (Nominal): 45mm
- Thread Length (Nominal): 30mm
- Drive Size: T20
- Head Diameter: 8mm
- Head Height, Overall: 3mm
- Category: Particle Board Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Reinforced Head
- Head Style: Pan Head
- Drive Style: 6Lobe Drive
- Drive Detail: Torx® Generic Alternative
- Thread Length: Part Thread
- Thread Direction: Right-Hand Thread
- Point: Standard Point
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: Art. 9045
- Form and Design:
- Reinforced Head
- Head Height, Overall:
- 3mm
- Head Diameter:
- 8mm
- Recess Size:
- T20
- Thread Length (Nominal):
- 30mm
- Length (Nominal):
- 45mm
- Diameter (Dimension):
- 4mm
- Diameter (Nominal):
- M4
- Standards and Specifications:
- Art. 9045
- Coating:
- Uncoated
- Material Grade:
- A2 Stainless Steel
- Material:
- Stainless Steel
- Point:
- Standard Point
- Thread Direction:
- Right-Hand Thread
- Thread Length:
- Part Thread
- Drive Detail:
- Torx(r) Generic Alternative
- Drive Style:
- 6Lobe Drive
- Head Style:
- Pan Head
- Brand:
- Aspen Fasteners
- System of Measurement:
- Metric
- Category:
- Particle Board Screws
- Order:
- Thread Cutting Fasteners
- Product Class:
- Externally Threaded Fasteners
- Shop by Material:
- Stainless Steel
- Shop by System of Measurement:
- Metric
-
Description
- Particle board screws are designed for use in dense woods such as particle boards or chipboards.
- A 6-lobe recess is also known as a hexalobular internal drive.
- Pan head screws are also known as raised cheese head screws.
- A2 stainless steel is functionally equivalent to 304 grade, also known as 18-8 stainless steel.
- Stainless steel significantly improves resistance to tarnishing or corrosion.
- Diameter (Nominal): M4
- Diameter (Dimension): 4mm
- Length (Nominal): 45mm
- Thread Length (Nominal): 30mm
- Drive Size: T20
- Head Diameter: 8mm
- Head Height, Overall: 3mm
- Category: Particle Board Screws
- System of Measurement: Metric
- Brand: Aspen Fasteners®
- Form and Design: Reinforced Head
- Head Style: Pan Head
- Drive Style: 6Lobe Drive
- Drive Detail: Torx® Generic Alternative
- Thread Length: Part Thread
- Thread Direction: Right-Hand Thread
- Point: Standard Point
- Material: Stainless Steel
- Material Grade: A2 Stainless Steel
- Coating: Uncoated
- Standards and Specifications: Art. 9045
