- Fender washers have a particularly large outside diameter in relation to the center hole.
- Fender washers are sometime referred to as Penny Washers.
- Use when a large bearing surface is required.
- Nylon 6/6 is a general purpose Polyamide with excellent tensile strength.
DIMENSIONAL ATTRIBUTES- Diameter (Nominal): M6
- Diameter (Dimension): 6mm
- Inside Diameter (Nominal): 6.4mm
- Inside Diameter (Minimum): 6.4mm
- Inside Diameter (Maximum): 6.62mm
- Outside Diameter (Nominal): 18mm
- Outside Diameter (Minimum): 17.57mm
- Outside Diameter (Maximum): 18mm
- Thickness (Nominal): 1.6mm
- Thickness (Minimum): 1.4mm
- Thickness (Maximum): 1.8mm
PRODUCT ATTRIBUTES- Category: Fender Washers
- System of Measurement: Metric
- Brand: Aspen Fasteners
- Form and Design: OD 3.0 X Diameter
- Material: Nylon
- Material Grade: Type 6/6
- Coating: Uncoated
- Standards and Specifications: DIN 9021 / ISO 7093
Product UPC Code:
692559765228
- Inside Diameter (Minimum):
- 6.4mm
- Diameter (Dimension):
- 6mm
- Thickness (Minimum):
- 1.4mm
- System of Measurement:
- Metric
- Standards and Specifications:
- DIN 9021 / ISO 7093
- Material:
- Nylon
- Thickness (Nominal):
- 1.6mm
- Shop by System of Measurement:
- Metric
- cad_3d_file_url:
- https://3d.aspenfasteners.com/assets/obj/ME379-6.zip
- Category:
- Fender Washers
- Shop by Material:
- Thermoplastics
- Coating:
- Uncoated
- Material Grade:
- Type 6/6
- Thickness (Maximum):
- 1.8mm
- Order:
- Flat Washers
- Diameter (Nominal):
- M6
- cad_3d_viewer_url:
- https://3d.aspenfasteners.com/viewer/?cad_model=obj/ME379-6
- Outside Diameter (Minimum):
- 17.57mm
- Form and Design:
- OD 3.0 X Diameter
- Product Class:
- Washers
- Outside Diameter (Nominal):
- 18mm
- Inside Diameter (Nominal):
- 6.4mm
- specifications_document_url:
- https://www.aspenfasteners.com/content/2D_PDF/product83/ME379-6.PDF
- Outside Diameter (Maximum):
- 18mm
- Brand:
- Aspen Fasteners
- Inside Diameter (Maximum):
- 6.62mm
- POS:
- ME379-6-00500
